Video Door Phones with Night Illumination to Operate Easily at Night, Up to 431 Apartments

Model Number: Door Phone System Al II,F3

Key Specifications/Special Features:

• 431 indoor phones for each door station
• Up to 8 door station for each building
• Anti-vandal and waterproof door station (optional)
• Door station with IR LED to ensure clear picture even at night
• Digital door station or direct-call station (optional)
• Keyboard with the night illumination to operate easily at night
• Talk and monitor with door station, unlock remotely and by password, each apartment has its own password
• Video and audio indoor phones are compatible
• Dingdong or chord music (optional)
• Indoor phone and the guard unit can call and communicate with each other
• Unlock by card (optional)
• Network or non-network system (optional)

Payment Details:

• Payment Terms:
  • T/T, L/C
• Minimum Order:
  • 100 Pieces

Delivery Details:

• FOB Price Range:
  • US$ 50 - US$ 150
• Lead Time:
  • 25 - 30 days

--------------
Leelen-Leading Wired video door phones China manufacturer

Villa Door Phone with 1/3-inch CCD/CMOS Camera, Night Vision, Rain Cover, Card Reader Optional

Model Number: Villa video door phone No.15

Key Specifications/Special Features:

• Features:
  • Outdoor station JB-304 villa intercom system
  • Color video intercom by handsfree, monitor and unlock
  • More than 10 melodies for ring selection
  • Used to sure the image clearly at night by IR
  • Four-wire system, easy to install and operating
  • Accepted to be connected with four indoor phones, most to each user of different floors
  • Accepted to be connected with four door stations, most to each user of several entrances
  • All indoor phones are accepted to call, transfer calling and communicate each other
  • Villa door station can be installed by surface mount
• Specifications:
  • Camera: 1/3-inch CCD/CMOS
  • Manual zoom: 9x
  • Viewing angle: 90°
  • Horizontal resolution: 420TVL
  • Video output: 1Vp-p/75Ω
  • Power: 18V (supplied by the indoor phone)
  • Wire: 4 wires
  • Environment temperature: -40 to 70 degrees Celsius
  • Dimensions: 74 x 142 x 32 or 93 x 168 x 52mm
  • Installation: surface mounts with rain cover, flush-mounted

Payment Details:

• Payment Terms:
  • T/T or L/C
• Minimum Order:
  • 100 Pieces

Delivery Details:

• FOB Port:
  • Xiamen
• FOB Price Range:
  • US$ 50 - US$ 150
• Lead Time:
  • 25 - 30 days

  --------------
  Leelen-Leading Wired video door phones China manufacturer


Video Door Phone with Touch Button, Cat-5, No Need to Cut Wires for Address Codes

Video Door Phone with Touch Button, Cat-5, No Need to Cut Wires for Address Codes

Model Number: Access control system No.10 (X)

Key Specifications/Special Features:

• JB-5000 multi-apartment intercom system
• System is applicable for single buildings, besides the common functions of calling/answering/unlocking
• Features and functions:
  • BUS cable, Plug-and-play
  • Available to run Cat-5 cable from the isolated module to indoor phones
  • Free address: do not need to cut wires for address codes
  • Up to 9999 apartments per building
  • Cast aluminum panel, flush mount
  • Night viewing with IP LED
  • Card reader optional
  • Extra indoor phones are available for every apartments
  • Various handsfree indoor phones are optional
  • Picture memory and burglar alarms are optional
  • Intercom between apartments
  • PIN code for entry
  • Isolation modules
  • Indoor phones do not require external power supply
• Technical specifications:
  • Door stations technical parameters:
    • Camera: 1/3-inch CCD
    • Display: LED or LCD
    • Minimum illumination: 0.01 lux
    • Video output: 1Vp-p/75Ω
    • Audio SNR: ≥25dB
    • Audio distortion: ≤7%
    • Working voltage: DC 12V ±10%
    • Standby current: ≤160mA (digit-call)
    • Working current: ≤410mA (digit-call)
    • Power supply: DC 12V ±10%
    • Environment temperatures: -40 to +70°C
• Indoor phones technical parameters:
  • Display: 4-inch CRT/TFT-LCD, 7-inch TFT-LCD
  • Resolution: 420TVL (4-inch B/W), or 300,000 pixels (color)
  • Working voltages: DC 32V ±10% and DC 12V ±10%
  • Standby current: ≤60mA
  • Working current: ≤260mA
  • Environment temperatures: -10 to +55°C
  • Power supply:
    • Power: 40W
    • Input voltages: AC 100 to 240V/50 to 60Hz, 0.5A maximum
    • Output voltages: DC 12V ±10% (model: L8-5001K-12), DC 32V ±10% (L8-5001K-32)
    • Current output: 3A (model: L8-5001K-12), 1.25A (model: L8-5001K-32)

Payment Details:

• Payment Terms:
  • T/T or L/C
• Minimum Order:
  • 100 Pieces

Delivery Details:

• FOB Port:
  • Xiamen
• FOB Price Range:
  • US$ 50 - US$ 150
• Lead Time:
  • 25 - 30 days



--------------
Leelen-Leading Wired video door phones China manufacturer

Villa Video Intercom Systems with CCD Sony Camera, Night Vision, Card Reader or Name Tag is Optional (2)

Villa Video Intercom Systems with CCD Sony Camera, Night Vision, Card Reader or Name Tag is Optional

Model Number: Door phone system XV, N60

Key Specifications/Special Features:

Specifications:
Display: 7-inch TFT LCD
More than 10 melodies for ring selection
Door station with 1/3-inch Sony CCD cameras, anti-vandal and waterproof panel
To sure the image clearly at night by IR night vision
4-wire system, easy to install and operating
Up to 4 door stations and 4 indoor phones
All indoor phones are accepted to call, transfer calling and communicate each other
Door station can be installed by surface mount or flush mount
Technical parameters:
Camera: 1/3-inch CCD (color), CMOS (B/W)
Minimum illumination: 0.01 Lux
Video output: 1Vp-p/75 Ohms
Working voltage: 18V DC± 10%
Working current: ≤500mA
Environment temperature: -40 to 70 degrees Celsius
Indoor phone technical parameters:
Display: 4 CRT/4 and 7 inches TFT LCD
Resolution: 960 x 234 pixels (4, 5, 5.8 inches)/1,440 x 234 pixels (7 inches)
Working voltage: 18V DC ± 10%
Working current: ≤500mA
Environment temperature: -10 to 55 degrees Celsius
Power supply technical parameters:
Input voltage: 100 to 240V AC
Output voltage: 18V DC
Output current: 1A
Power plug style: optional
All trademarks shown here are for reference purposes only. They are the property of their respective owners, and we are not authorized to sell items bearing such trademarks.

Payment Details:

Payment Terms:
T/T and L/C at Sight
Minimum Order:
1 to 99 Pieces

Delivery Details:

FOB Port:
Xiamen
FOB Price Range:
US$ 25 - US$ 150
Lead Time:
25 - 30 days

Product Certifications:


Certificate Standard: CE
View scanned certification
Certificate Number: 0708124-34
Issue Date: 14-Sep-2007
Issued By: EMC and LVD
Scope/Range: All Components of Intercom

Certificate Standard: CCC
View scanned certification
Certificate Number: 2006031902000284
Issued By: CNAS
Note: Not all certifying agents offer online lookup, and some have a lag time for posting new certificates. If you are unable to find a certificate online, contact the certification agency or supplier for further verification.
--------------
Leelen-Leading Wired video door phones China manufacturer

Villa Video Intercom Systems with CCD Sony Camera, Night Vision, Card Reader or Name Tag is Optional (1)

Villa Video Intercom Systems with CCD Sony Camera, Night Vision, Card Reader or Name Tag is Optional

Model Number: Door phone system XV, N60

Key Specifications/Special Features:

Specifications:
Display: 7-inch TFT LCD
More than 10 melodies for ring selection
Door station with 1/3-inch Sony CCD cameras, anti-vandal and waterproof panel
To sure the image clearly at night by IR night vision
4-wire system, easy to install and operating
Up to 4 door stations and 4 indoor phones
All indoor phones are accepted to call, transfer calling and communicate each other
Door station can be installed by surface mount or flush mount
Technical parameters:
Camera: 1/3-inch CCD (color), CMOS (B/W)
Minimum illumination: 0.01 Lux
Video output: 1Vp-p/75 Ohms
Working voltage: 18V DC± 10%
Working current: ≤500mA
Environment temperature: -40 to 70 degrees Celsius
Indoor phone technical parameters:
Display: 4 CRT/4 and 7 inches TFT LCD
Resolution: 960 x 234 pixels (4, 5, 5.8 inches)/1,440 x 234 pixels (7 inches)
Working voltage: 18V DC ± 10%
Working current: ≤500mA
Environment temperature: -10 to 55 degrees Celsius
Power supply technical parameters:
Input voltage: 100 to 240V AC
Output voltage: 18V DC
Output current: 1A
Power plug style: optional
All trademarks shown here are for reference purposes only. They are the property of their respective owners, and we are not authorized to sell items bearing such trademarks.

Payment Details:

Payment Terms:
T/T and L/C at Sight
Minimum Order:
1 to 99 Pieces

Delivery Details:

FOB Port:
Xiamen
FOB Price Range:
US$ 25 - US$ 150
Lead Time:
25 - 30 days

Product Certifications:


Certificate Standard: CE
View scanned certification
Certificate Number: 0708124-34
Issue Date: 14-Sep-2007
Issued By: EMC and LVD
Scope/Range: All Components of Intercom

Certificate Standard: CCC
View scanned certification
Certificate Number: 2006031902000284
Issued By: CNAS
Note: Not all certifying agents offer online lookup, and some have a lag time for posting new certificates. If you are unable to find a certificate online, contact the certification agency or supplier for further verification.
--------------
